Amore Mio - 2016

45 metre Custom
Semi-displacement

Power with comfort

The highly efficient semi-displacement aluminium hull, designed by Heesen’s in-house naval architects, provides both rapid acceleration and smooth power, so owners and guests arrive at their destination stirred but not shaken. With a range of 2.750nm Amore Mio can cross the Mediterranean with ease, or cruise the entire length of the Caribbean from St. Barths to Grenada stopping at as many islands as the owner chooses - on only one tank of fuel.

First impressions

On every level, inside and on deck, this yacht has been designed to provide the very rare combination of space, speed, style and safety.

Step aboard

Designed by Cristiano Gatto, the interior of Amore Mio is a fusion of contemporary style and sophisticated elegance, all blended in a very welcoming environment. Precious details are incorporated in the design and contribute to the warmth and cosiness of the ambiance.

Specifications

General

Hull type: Semi-displacement

Exterior design: Omega Architects

Interior design: Cristiano Gatto Design Team

Hull: Aluminium

Dimensions

Length over all: 45.00 metres / 147 feet 8 inches

Beam over all: 8.40 metres / 27 feet 7 inches

Draft (half load): 2.67 metres / 8 feet 9 inches

Tonnage: approx. 360 GT

Accommodations

Crew: 7

Guests: 10

Cabins: Full-beam owner’s stateroom, two double guest suites and two twin guest suites

Technical Details

Maximum speed (half load): 30 knots

Range: 2,750Nm at 12 knots

Fuel capacity: 52,000 litres / 13,730 US Gallons

Fresh water: 10,000 litres / 2,640 US Gallons

Propulsion Details

Main engines: 2 × MTU 16V 4000 M73L

Maximum power: 2 x 2,880kW

Main generators: 2 x Kilo-Pak, each 99kW

Bowthruster: ZF-Marine 80kW, hydraulically driven

Stabilisers: 3 x Gyro Seakeeper M26000, zero speed

General arrangement

Wheelhouse deck

Main deck

Lower deck
