My Secret - 2012

47m Steel
Displacement

Power never means compromising on luxury

At just under 500GT, this 47-metre steel displacement yacht has the largest volume in her class. Her four deck levels include a sundeck of almost 90 square metres, and a foredeck lounge and sun pad for added privacy even when the yacht is moored stern to. What makes the concept so special is the combination of unprecedented flexibility combined with Heesen’ standards of construction. The result? A custom-built 47m yacht that represents the best value on the market.

First impressions

My Secret is our ninth 47 metre, steel displacement yacht. Her specially developed bulbous bow creates an anti-wave for a smoother path through the water. The result of this hull efficiency is a reduction in the engine power needed to achieve any given speed. Less power required means less fuel used. My Secret attains a maximum speed of 15 knots and was specifically designed to create the largest possible internal volume under 500GT.

Step aboard

Interiors by Bannenberg and Rowell evoke Californian style of the 1940s and 1950s. The finest woods, stones and metals have been expertly integrated with our trademark precision and dedication to weight reduction. The result – a striking design that effortlessly combines practicality and extravagant style. Bronze, leather and light and mid-tone wenge detailing have been used throughout the yacht, with intricate panels laid on the floors and other areas.

Specifications

General

Hull type: Displacement

Exterior design: Omega Architects

Interior design: Bannenberg & Rowell Design

Hull: Steel

Dimensions

Length over all: 46.70 metres / 153 feet 2 inches

Beam over all: 8.83 metres / 29 feet

Draft (half load): 3.08 metres / 10 feet 10 inches

Tonnage: approx. 499 GT

Accommodations

Crew: 10

Guests: 10

Cabins: Full-beam owner’s stateroom, two double suites and two twin guest suites

Technical Details

Maximum speed (half load): 15 knots

Range: 4,000Nm at 12 knots

Fuel capacity: 60,000 litres / 15,850 US Gallons

Fresh water: 20,000 litres / 5,300 US Gallons

Propulsion Details

Main engines: 2 x MTU 8V 4000 M63

Maximum power: 2 x 1,000kW

Main generators: 2 x Kilo-Pak, each 99kW

Bowthruster: HRP 90kW, hydraulically driven

Stabilisers: Naiad Dynamics, 2 fins, type 621, zero speed

General arrangement

Sun deck

Wheelhouse deck

Main deck

Lower deck
